An “AC BRACKET” is a heavy-duty support structure used to mount the exterior condenser unit of a split air conditioning system, or a heavy window AC unit, securely to an external wall. These brackets are designed to protect the unit from debris, snow, and flooding while reducing vibration noise.
AC BRACKET Description & Features
- Material:Â Usually constructed from galvanized steel or stainless steel, with a weather-resistant, powder-coated finish (often gray or white) to prevent rust.
- Design:Â The structure consists of an L-shaped folding frame that supports the compressor, with a horizontal support bar and adjustable legs for leveling.
- Load Bearing:Â Typically, they can support heavy loads ranging from 100 kg (220 lbs) up to 200 kg (440 lbs).
- Components:Â Usually includes rubber vibration pads (to reduce noise) and necessary mounting hardware (bolts, anchors).
- Compatibility:Â Designed to work with various outdoor condensing units, particularly for 1 to 2.5-ton split systems.
Common Dimensions & Sizes
Brackets are available in several sizes, generally categorized by the capacity of the AC unit:
Brackets are available in several sizes, generally categorized by the capacity of the AC unit:
- 600×600 mm (23.6 x 23.6 inches):Â A standard, common size for larger, heavy-duty split outdoor units (1-3 tons).
- 550×550 mm (21.6 x 21.6 inches):Â Often used for 2-3 ton AC units.
- 460×460 mm (18 x 18 inches):Â Common for smaller 1.5 HP – 2 HP units.
- Adjustable Width:Â Many brackets feature a “universal” design allowing the arms to extend to fit different unit sizes.
Example ACBRACKET Specificatio
- Thickness:Â Generally 1.5mm to 2mm thick steel for high strength.
- Weight Capacity:Â ~150 kg (330 lbs) to 200 kg (440 lbs).
- Finish:Â Powder-coated/Galvanized.
Disclaimer: The exact dimensions and load capacities may vary based on the specific manufacturer (e.g., Generic, Skilltech, etc.).
